Schlage Commercial ALX50PD-SPA-625-47267042-47267101 ALX50P Sparta Entrance/Office Lock, Bright Polished Chrome

Entrance/Office Lock, Keyed function, 6-Pin Cylinder,”C” Keyway, 2-3/4″ Backset Square Corner Deadlatch, 4-7/8″ ANSI Strike, 625 Bright Chrome
ALX SeriesCylindrical Lock

The proven AL Series has evolved
As a Grade 2 lock, the AL Series has always offered a combination of strength and durability alongside Schlage trusted key system options at a price point favorable to any application. Though these qualities remain, the lock has changed. ALX Series’ features now deliver flexibility and value beyond strength and security. X Factor qualities, born from modular design, define a lock that exceeds expectations. AL Series’ evolution to the ALX Series is a revolution in lock design.

Why modular design is important
The Schlage ALX Series gives you the ability to use it as you would any other lock: ordered and delivered as a complete, configured product ready for installation. However, in its new modular design, ALX Series offers you the flexibility to utilize the separate components of chassis, function and lever packaged kits to create a lock to meet your needs on demand. So whether you are a distributor wanting to offer same day pickup on configured locks in uncommon levers and finishes, a locksmith wanting truck stock solutions that eliminate call backs, or a facility manager wanting to repurpose rooms and change lock functions without the expense of new hardware, ALX Series can work for you.

Installing
Access interactive, visual instructions for installation on your smart phone, any time, any place. ALLEhelp.com/ALX

Chassis: Material:

• Zinc and steel, zinc dichromate plated for corrosion resistance

Door thickness:

• Standard: 1 3/8″ to 1 3/4″ + .012 to accommodate wrap

Functions:

• 9 available functions with Vandlgard field configurable option on locking functions

Trim: Handing:

• Non-Handed

Levers:

• Standard: 10 designs, pressure cast zinc, plated to match product finish specification
• Optional: Tactile feature – Milled levers: Athens (8AT); Latitude (8LT); Longitude (8LN); Rhodes (8RO); and Sparta (8SP)
• Knurled levers: Boardwalk (8BK); Broadway (8BW); and Tubular (8TR)

Roses:

• Wrought brass, bronze or zinc plated to match finish specification
• Standard: 3 7/16″ diameter. Blank outside rose is 3 1/2″ diameter

Finishes:

• 10 available: 605, 606, 612, 613, 619, 622, 625, 626, 626AM, 643e

Latches: Backset:

• Standard: 2 3/4″
• Optional: 2 3/8″, 3 3/4″, 5″

Faceplate:

• Standard: 1 1/8″ x 2 1/4″ square corners
• Optional: Multiple options with square or radius corners

Bolt:

• Standard: 7/8″ bolt diameter, up to 1″ housing diameter, 1/2″ throw in Stainless Steel
• Optional: 1″ bolt diameter with 1/2″ throw, 3/4″ anti-friction fire latch

Strike:

• Standard: ANSI Curved Lip: 1 1/4″ x 4 7/8″ x 1 3/16″
• Optional: T strike

Cylinders: Format:

• Standard: Conventional 6-pin in solid brass
• Optional: Full size and small format IC cylinders

SL option:

• 7-pin Conventional and FSIC format cylinders using small format A2 pinning that share SFIC cylinder’s Everest 29R restricted keyway

Construction options:

• Conventional: Cylinders can be ordered as “construction” and will be shipped with a split key and separately packaged change keys
• FSIC and SFIC: Cylinders can be purchased as returnable/refundable cylinders and SFIC is also offered as a disposable cylinder

Less cylinder:

• Options to fit Schlage Primus and 5 competitive cylinders

Keying: Keyway:

• Standard: Everest 29 S123 patented open keyway, keyed different (KD)
• Optional: Classic open, Everest 29 restricted, and legacy keyways

Enhanced security options:

• Primus XP program and factory master keying

Warranty:

• 10-year limited

Certifications: ANSI/BHMA:

• Certified A156.2-2011 Series 4000, Grade 2; exceeds standard for lever and spindle strength and durability

ICC:

• Complies with ICC A117.1 for Accessible and Usable Buildings and Facilities

UL/cUL:

• All locks listed for A label single fire door 4′ x 8′ for 3-hours.
• Upgrade options available to achieve 4′ x 10′ 3-hour; pair doors 8′ x 8′ 3-hour; and 8′ x 10′ 90-minute.
• Letter F and UL symbol on latch front indicate listing.

UL 437:

• Optional UL listed high-security cylinders available in Conventional format

CA Fire Code:

• All levers with a return to door of 1/2″ (64 mm) or less comply
• (Boardwalk, Longitude, Omega, Rhodes, Saturn, Sparta, and Tubular)

FL Building Code:

• ASTM E1886 and E1996 impact and cycle/Miami-Dade equivalent TAS 201 and TAS 202.
• ASTM E330 static load/Miami-Dade equivalent TAS 202.

Federal:

• Meets FF-H-106C Series 161

ADA compliant:

• All lever designs meet Americans with Disabilities Act requirements

Functions: Passage latch:

• Schlage – 10 ANSI – F75
• No key; plain lever both sides; spring latch
• Both levers always unlocked

Bath/bedroom privacy lock:

• Schlage – 40 ANSI – F76
• No key; emergency access coin turn outside; push button inside; spring latch
• Inside push button locks outside lever
• Turn inside lever or close door to release button and prevent lock-out; outside coin turn provides emergency access
• Field selectable Vandlgard® feature
• Inside lever is always free for immediate egress

Entrance/office lock:

• Schlage – 50 ANSI – F82
• Key cylinder outside; push button inside; deadlatch
• Inside push button locks outside lever
• Unlock with key outside or by rotating inside lever
• Field selectable Vandlgard® feature
• Inside lever always free for immediate egress

Hospital privacy lock:

• Schlage – 44
• No key; emergency turn-button outside; push button inside; spring latch
• Inside push button locks outside lever
• Turn inside lever or close door to release button and prevent lock-out; outside turn-button provides emergency access
• Field selectable Vandlgard® feature
• Inside lever is always free for immediate egress

Single dummy trim:

• Schlage – 170
• No key; rigid plain lever outside; no hardware inside; no latchbolt
• Use as door pull or matching inactive trim
• Notes: Not available for in-field function changes.

Double dummy trim:

• Schlage – 172
• No key; rigid, plain lever both sides; no latchbolt
• Use as door pull or matching inactive trim
• Notes: Latch cover available. Not available for in-field function changes.

Classroom lock:

• Schlage – 70 ANSI – F84
• Key cylinder outside; plain lever inside; deadlatch
• Key in outside lever locks or unlocks outside lever
• Field selectable Vandlgard® feature
• Inside lever always free for immediate egress

Entrance lock:

• Schlage – 53 ANSI – F109
• Key cylinder outside; push/turn button inside; deadlatch
• Inside button locks outside lever by pushing button or pushing and turning button
• Pushed button: unlock with key outside or by rotating inside lever
• Pushed/turned button: key outside retracts latch only; unlock by returning inside button to home position then using key or rotating inside lever
• Field selectable Vandlgard® feature
• Inside lever always free for immediate egress

Storeroom lock:

• Schlage – 80 ANSI – F86
• Key cylinder outside; plain lever inside; deadlatch
• Outside lever always fixed
• Key can retract the latch
• Field selectable Vandlgard® feature
• Inside lever always free for immediate egress

Lever designs:

• Athens (ATH)
• Boardwalk (BRK)1
• Broadway (BRW)
• Latitude (LAT)
• Longitude (LON)1
• Omega (OME)1,2
• Rhodes (RHO)1
• Saturn (SAT)1
• Sparta (SPA)1
• Tubular (TLR)1
• 1 Boardwalk, Longitude, Omega, Rhodes, Saturn, Sparta and Tubular levers comply with California State code for return within 1/2″ of door face.
• 2 Omega levers not available for kit system orders.

This product contains 1 cylinders per lock and is typically keyed alike in quantities of 1.
