IVES 224XY-83-28 224XY Full Mortise – Door Edge Protector

83″ length, aluminum geared hinge, door edge protector, US28 Clear Anodized Aluminum
224XY Aluminum Geared HingeFull mortise – door edge protector

Geared continuous hinges are designed to last the life of a building by distributing the weight of a door along the entire length of its frame. The unique design reduces the high amount of stress normally associated at the top of the door and frame on butt hinge applications. Not only does this reduce hinge failure, it also keeps a door in constant alignment, eliminating the chance of door sag. These characteristics make continuous hinges suitable for high-use and high-traffic doors.

The geared continuous hinge has no pin. Instead, these hinges utilize a single gear section for the leaf and a separate gear section for the frame side of the door. The two are held in place by a full length cover channel and rotate on a series of bearings. The design of a continuous hinge eliminates the spacing between the hinges, which helps prevents fingers from being pinched, making it a safer device than traditional hinges. These benefits result in higher efficiency and less maintenance, maximizing the value of a door opening investment.

Features:

• For 1 3/4″ doors

• Door edge protector

• Patented center loaded, interlocking bearing design

• Non-handed for custom cut lengths

• 1/16″ door inset

• 48″ Maximum door width

• Beveled or square edge doors

• Frame guidance lip is extended further for retrofit applications to cover existing heavy weight architectural hinge preps

• For doors weighing up to 450 pounds without reinforcing, 600 pounds with reinforcing

• For lead-lined application consult factory for engineering specials

Specifications: Certifications:

• Meets ANSI 156.26 for 150lbs and 300lbs
• UL10C certified

Standard lengths:

• 83″, 85″, 95″, 119″

Standard mounting hardware:

• 12-24 x 3/4″ Steel self drilling/self tapping phillips head screw

Finishes:

• Clear Anodized (US28)
• Dark Bronze Anodized (313AN)
• Black Anodized (315AN)
• Custom anodizing and painting are available, consult factory.

Options: HT:

• Hospital tip

EPT:

• Electric power transfer

TWP CON:

• Electrical through-wire panel with Allegion Connect

Optional mounting hardware: SECHM:

• Security screws – hollow metal door and frame

SECWDHM:

• Security screws – 1/2 wood, 1/2 hollow metal

SECWDWD:

• Security screws – wood door and frame

TEKWD:

• 1/2 self drill, self tap 1/2 wood

WD:

• Wood door and frame
